Asahi Series SP110-B Beadless Welding Machine for use on PP, PPn and PVDF Piping Systems

Asahi's SP110-B beadless welding machine controls all equipment movements and parameters during each phase of the welding process (heating, joining and cooling). This full automation eliminates operator influence during the fusion process and provides unmatched repeatability. The large size range of the tool allows the users to work without the need for multiple tool on a project. SP110-B can be used on 20mm to 110mm (1/2" to 4") piping systems.

The completely automated fusion process provides unmatched welding reliability, ease of use and short weld times. An automated planing depth feature enhances fabrication capabilities. The magnetic clamp inserts make pipe size change over quick. An internal validation progrm provides several QA sources including multiple label printout, copy label printout, stored electronic data and a PC download program. SP110-B requires the use of welding balloons and is best used for PP, PPn and PVDF thermoplastic piping system welds.
