Hayward EAUTB Series Actuated Ball Valve, 1-1/2" PVC TB Series True Union Ball Valve, EAU Series Electric Actuator
Item #EAUTBH115STV
- UL / CSA Listed Motor
- Thermoplastic NEMA 4/4X Enclosure
- 2.5 Second, 90° Cycle Time
- Permanently Lubricated Gear Train
- Actuator Brake
- 90 or 180° Operation
- Undirectional, Not Reversing
- Terminal Block Connections
- Standard 120 VAC
EAUTB Series is a package unit of an EAU actuator and a TB Series ball valve. The EAU actuator comes prewired with a terminal strip, and one auxiliary limit switch. Also includes a TB Series ball valve in PVC with FPM or EPDM o-rings. Socket and threaded end connections come with the valve. Corrosion ResistantHayward EAU Series Electric Actuatorscome standard with an all-polypropylenehousing for superior corrosion resistance.These NEMA 4 plastic housings can standup to harsh environmental conditions andcorrosive conditions, places where a metalactuator has to be painted or coated just tosurvive. Best for On/Off ApplicationsThese low cost, high quality electric actuatorsare the best choice for True Union andThree-Way Ball Valves up to 2" sizes wherea manual override is not required and controloptions are not needed.
