IPolymer 1/2" Stopcock Valve, Flare Connection, PTFE Construction, 2-Way Ends
Item #SC-712
- PTFE construction for media wetted surfaces
- Non-wetted components are polypropylene
- All models can bepanel mounted
- Can be used in high ambient temperatureenvironments
- Media operating pressure = 60 psi
- Media operating temperature = 230° F
IPolymer stopcock valves are precision machined devices that function in much the same way as a ball valve. When the handle points in the direction of flow, the valve is fully open; when the handle points perpendicular to the direction of flow, the valve is fully closed; and at the 45° position the valve is halfway open and thereby has a metering effect on the media flow.
The Stopcock features an all PTFE wetted surface design which is ideally suited for harsh chemical and corrosive media and environments. The body, stem and ports are constructed from PTFE. For standard applications, external non-wetted components are constructed from polypropylene. All configurations are optionally available as panel mounted and/or high ambient temperature models.
